Electric Fork Trucks

CPD50L1

540A/80V
4000mm (Duplex Mast)
5000kg
1800mm

The EP CPD50L1 electric forklift offers a 5000kg capacity, 4000mm duplex mast, and 540A/80V lithium-ion battery—ideal for heavy-duty applications.

More Information
Purchase From: £41,954.00 Exc. VAT
01600 800 800 WhatsApp Email

The CPD50L1, an upgraded version of EP’s iconic heavy-duty forklift truck CPD50F8, is designed to meet the evolving demands of modern intralogistics applications. This electric forklift combines aesthetics with functionality, offering an efficient solution for various industries.

High-Performance 5-Ton Li-ion Forklift for Heavy-Duty Work

Built for the toughest applications: beverage, timber, metal, construction, yards.
Suitable for container loading thanks to the 2250mm overhead guard height.

Compact, Optimised Chassis for Better Manoeuvrability

Shortened length to face of forks 2900mm.
Tight 2675mm turning radius.
Great handling in warehouses, loading bays, and restricted sites.

Two Lithium Battery Options for Any Duty Cycle

Standard: 80V 560Ah
Optional: 80V 690Ah for intensive multi-shift operations.
Li-ion benefits:
Zero maintenance
No emissions
Opportunity charging


IP65 external plug for easy charging without opening covers.

Higher Travel Speed = Higher Productivity

16 km/h laden
18 km/h unladen
Faster warehouse turnover vs older CPD50F8 models.

Optional Hydraulic Joystick for Fatigue-Free Operation

Controls include:
All hydraulic functions (including 4th way)
Driving direction (F–N–B)
Horn
Emergency stop
Located on armrest for minimal operator effort.

Proven Components & More Precise Lifting

Uses reliable, market-proven motors, controllers, mast & drive units.
New hydraulic pump = quieter + smoother lifting.

Improved Ergonomics & Low Seat Height

Seat height 1208 mm — lower than many 5T forklifts.
Makes entry/exit easier & reduces operator fatigue.

Manufacturer

EP Equipment

Model

CPD50L1

Fuel Type

Electric — 80V Li-ion

  • 560Ah (standard)
  • 690Ah (optional)

Side Shift

Optional:

  • Built-in sideshifter
  • External shifter
  • Fork positioner

Capacity

5000 kg

Lift Height

3000 mm

Mast Type

Standard 2-stage mast (3000mm)
Optional triplex (4.5m) for container operations
Other mast heights not listed but can be customised

Health & Safety

Hydraulic + mechanical service brake
Mechanical parking brake
OPS system (optional)
LED front lamp (standard)
Optional rear LED
Optional warning lamp
Optional 2-front / 1-rear blue lights
Optional area warning lamp (left/right red)
Turn signal lights
Optional full cabin / semi-cabins
Seatbelt logic switch upgrade available
Lower seat height improves entry/exit safety

Additional Info

Travel speed: 16/18 km/h (laden/unladen)
Lift speed: 0.30 / 0.46 m/s
Lowering speed: 0.45 / 0.51 m/s
Gradeability: 15% / 20%
Drive motor: 18 kW
Lift motor: 25.4 kW
Turning radius: 2675 mm
Forks: 55 × 150 × 1070 mm
Ground clearance: 130–150 mm
Service weight: 7000 kg
Tyres: Solid rubber (non-marking optional)
Overall width: 1550 mm
Overall length: 3970 mm
Energy consumption: 14.38 kWh/h
Optional 80V 150A / 200A chargers
Optional telematics
Optional traction pin
Optional fire extinguisher (not listed but normally available via cabin kit)
datasheet-CPD50L1

Download our product specification for more in-depth product information

Hire a truck

Whether you're moving equipment, making deliveries, or tackling a big job—iLift offers reliable, well-maintained trucks ready when you are. Choose from flexible rental options with no hidden fees.

We make it easy: fast bookings, clear pricing, and a friendly team to help you pick the right vehicle.

Get on the road today—call now or book online in minutes!

Rent now

iLift Recommends

We Think You May Also Like

More information

Application.
CPD50l1 can be applied in heavy loads (up to 5t), especially in metal industry and construction materials.
